Kia Rio: User Settings Mode (for type B cluster) / Icy Road Warning Light
This warning light is to warn the driver the road may be icy.
When the following conditions occur, the warning light (including Outside Temperature Gauge) blinks 5 times and then illuminates, and also a warning chime sounds once.
- The temperature on the Outside Temperature Gauge is below approximately 4°C (40°F).
✽ NOTICE
If the icy road warning light appears while driving, you should drive more attentively and refrain from speeding, rapid acceleration, sudden braking, and sharp turns.
Warning messages appear on the LCD to warn the driver. It is located in the center of the instrument cluster. The warning message may appear differently depending on the type of instrument cluster and some may not show the warning message at all.
NOTICE - Warning lights Make sure that all warning lights are OFF after starting the engine. If any light is still ON, this indicates a situation that needs attention.
